Description
Technical Characteristics | Process Function | |
Overall | 4000(L)*1700(W)*2200(H)mm | Step 1:Feeding |
Weight | 1500kg | Step 2:Dust Clean |
Working Speed | 5-25m/min | Step 3:Heating |
Total Power | 36w | Step 4:Glue Spreading |
Heating Power | 6.5kw | Step 5:Heating |
Power of the heating gun | 800W*8 | Step 6:Film Laminating |
System | PLC Touch screen | Step 7:Wrapping |
Certification | CE | Step 8: Auto outfeeding |
Material Characteristics (customized Avaiable) | ||
Max. Film Covering Width | 700/800/900/1000/1100/1350mm | |
Max. process Thick | 90mm | |
Min Process Length | 600mm | |
Max. Diameter of Roll material | 400mm |
